6185
PR ELECTRONICS
LOOP-POWERED ISOLATOR1-; 2- AND 4-CHANNEL GALVANIC ISOLATION– SLIMLINE CHANNEL WIDTH OF LESS THAN 6 MM– NO SEPARATE SUPPLY NECESSARY– LOW RESPONSE TIME– HIGH NOISE SUPPRESSIONENVIRONMENTAL CONDITIONSSPECIFICATIONS RANGE....................................... -20°C TO +60°CCALIBRATION TEMPERATURE................................. 20...28°CRELATIVE HUMIDITY............................................ < 95% RH (NON-COND.)PROTECTION DEGREE........................................... IP20MECHANICAL SPECIFICATIONSDIMENSIONS (HXWXD)..................................... 109 X 23.5 X 104 MMWEIGHT APPROX................................................ 155 / 180 / 230 G (1 / 2 / 4CHANNELS)DIN RAIL TYPE................................................... DIN 46277WIRE SIZE........................................................ 1 X 2.5 MM2 STRANDED WIRESCREW TERMINAL TORQUE.................................... 0.5 NMCOMMON SPECIFICATIONSISOLATION VOLTAGETEST VOLTAGE.................................................... 2 KVACRESPONSE TIMERESPONSE TIME (0...90%; 100...10%)............. < 4 MSINTERNAL CONSUMPTION; PERCHANNEL........................................................... 40 MWVOLTAGE DROP................................................... < 1.8 VDC; MIN.VOLTAGE DROP................................................... 1.8 V + (IOUT.*RLOAD); MAX.SIGNAL / NOISE RATIO......................................... MIN. 60 DB (0...100 KHZ)ACCURACY........................................................ BETTER THAN 0.1% OF SELECTEDRANGEEMC IMMUNITY INFLUENCE................................ < ±0.5% OF SPANINPUT SPECIFICATIONSCURRENT INPUTMEASUREMENT RANGE....................................... 0...23 MAINPUT RESISTANCE.............................................. ? 90 ? + RLOAD (@ 20 MA)OUTPUT SPECIFICATIONSCURRENT OUTPUTSIGNAL RANGE................................................... 0...23 MAMIN. SIGNAL RANGE............................................ 1:1LOAD (MAX.).................................................... 20 MA/600 ?/12 VDCLOAD STABILITY.................................................. < 0.03% OF SPAN / 100 ?CURRENT LIMIT.................................................... 50 MAVOLTAGE LIMIT.................................................... 15 VDC*OF SPAN.......................................................... = OF THE PRESENTLY SELECTEDRANGEAPPROVALSEMC............................................................... EN 61326-1EAC TR-CU 020/2011................................... EN 61326-1
The equipment with type Accessoires is manufactured by PR ELECTRONICS and commercialized under the reference 6185. This product comes from the NC range. We guarantee the equipment in all the services offered for 12 months.
| Reference : | 6185 |
| Brand : | PR ELECTRONICS |
| Range : | NC |
| Category : | Remote control Accessories |
Also discover our entire NC range for the PR ELECTRONICS brand
The part reference 6185 or from the PR ELECTRONICS brand from the NC range is available quickly and guaranteed for 12 months on our site.
Warning, only 1 left
12 months guarantee
PLSWISS SA is not an authorised distributor PR ELECTRONICS.
FACTORY WARRANTY MAY NOT APPLY. PLSWISS 1-YEAR WARRANTY INCLUDED
The references, brands and logos used are the property of their respective owners.
The representation, description or sale of the products bearing these references, trademarks or logos is for identification purposes only.
They are not intended to indicate any affiliation with or authorization by any rights holder.
Related Products for the product 6185
Information
Payment
Payment due date is 30 days billing date.
All our transactions are secured by Banque Cantonale Vaudoise By default the payments are made in the local currency in Francs Suisse (CHF). We also accept payments in Euros (€).
Payments are made by bank transfer.
Transport
All our deliveries are provided by express transport services and will be chosen according to the type of equipment to be sent, the size and the weight of the package to be delivered. By default we work with the carrier UPS or TNT for small parcels and with TRANSPORTS VUALLIAT for pallets or cumbersome package.
Warranty
All equipment that we repair or recondition according to our procedures are guaranteed for 12 months from the date of shipment.
If upon receipt of the equipment in your premises, you install it and notice a partial or total malfunction, please return it to us for urgent support. Return address of the material : PLSWISS SA - Route de l'Ancienne Papeterie - 1723 Marly - Switzerland
Revaluation - Buy back
You have unused parts, you modernize your installation? Do not throw away your equipment anymore, but propose them to us to be revalorized!
Galery of the product 6185 PR ELECTRONICS
